  Home > Product Center > Scissor
Note: According to user requirements for different voltage and frequency product (specific parameters see the equioment signs)　　(Optional color)

HY-JSZM-B-8340-X

IN-GROUND SCISSOR LIFT

CHARACTERISTICS

1.In-ground mounted, occupied small space.
2. Electric control pneumatic release, safety and reliable.
3.Hydraulic system adopts the advanced integrated valve plate oil and imports of seal parts.
4.Power failure can adopt manually will the car drop out.
5.Oil cylinder with upper return oil, prevent oil cylinder rust.

TECHNICAL SPECIFICATIONS

  • 4000kgLifting Capacity
  • (Main) 1700mm (Jack) 450mmLifting Height
  • 340mmMin. Height
  • 50s-60sLifting Time
  • 4500mmLength Of The Platform
  • 600mmPlatform Width
  • 3.0kw-380v or 3.0kW-220vMotor Power
  • 24MPaOil Pressure Rating
  • 0.6-0.8MPaAir Pressure
  • 1900kgWeight

  DIMENSIONS (mm)
